Container

Container
Container glass is used for bottles, jars and other vessels and has a higher content of water-insoluble oxides, providing chemical durability against water. This is an important property when storing beverages and food.

The production process for container glass has several points where temperature measurements are key, from thermal imaging of the melt tank through to temperature measurements in the forehearth and monitoring cooling in the annealing process.

Accurate measurements at critical locations are vital to supporting consistent quality in container glass manufacture. AMETEK Land has a range of advanced, high-precision instruments, specifically designed for the glass industry, to produce the required results.

APPLICATION NOTE
TEMPERATURE MEASUREMENT SOLUTIONS FOR CONTAINER GLASS APPLICATIONSTEMPERATURE MEASUREMENT SOLUTIONS FOR CONTAINER GLASS APPLICATIONS
Accurate and reliable temperature measurements at key process locations are vital to ensure consistent quality throughout container glass manufacture. AMETEK Land provides proven solutions throughout the production process to deliver these measurements, supporting an efficient process and high-quality product. Read More >

  • Applications +

    • Batch Inlet
      Batch Inlet

      Measurement at the batch inlet provides thermal monitoring of the glass raw materials for quality control. We recommend the LWIR-640 thermal imager or RT8 thermometer for this application.

      Keep Reading

    • Melt Tank – Inside Refractory
      Melt Tank – Inside Refractory

      Optimum process control, energy efficiency and tank condition can be controlled through refractory wall measurements. The NIR-B Glass, Cyclops 100L, Model FG and SPOT M100 are recommended.

      Keep Reading

    • Melt Tank - Bulk Glass
      Melt Tank - Bulk Glass

      Measuring the temperature of the melted glass in the tank provides measurements for process control and efficiency. Our recommended solutions are the NIR-B Glass, Cyclops 100L, Model FG and SPOT M100.

      Keep Reading

    • Melt Tank - Outside
      Melt Tank - Outside

      An LWIR-640 thermal imager is recommended for continuous monitoring of the melt tank exterior. This monitors the tank condition, providing warnings of possible glass break-out or refractory failure.

      Keep Reading

    • Regenerators
      Regenerators

      Accurate, reliable temperature measurements are essential for this important area of the tank. The solutions recommended by AMETEK Land are the Model FG, SPOT M100 and Lancom 4.

      Keep Reading

    • Flue Gas
      Flue Gas

      Glass production produces flue gas emissions which must be monitored. We offer the Lancom 4, Model 4500 MkIII and WDG 1200/1210, depending on process needs.

      Keep Reading

    • Distributors and Feeders
      Distributors and Feeders

      Measurements are essential to help control the flow of molten glass into uniform gobs. The Model FG and Cyclops 100L provide the thermal monitoring required for process and quality control.

      Keep Reading

    • Forehearth
      Forehearth (Container / Fibreglass / Rockwool / Speciality / Tableware)

      Temperature control here is vital to glass condition. The fibre-optic Model FG radiation thermometer is specifically designed for this measurement, while the Cyclops 100L and Lancom 4 are also recommended.

      Keep Reading

    • Gob
      Gob (Container / Speciality / Tableware)

      Accurate gob temperatures maintain the relationship between glass viscosity and gob weight. The portable Cyclops 100L and on-line SPOT M100/R100 fibre optic thermometer offer solutions for this measurement.

      Keep Reading

    • Mould
      Mould

      The molten gobs of glass are shaped into containers here prior to annealing. We recommend temperature monitoring of the glass is achieved by using the SPOT M160, R160 or M210.

      Keep Reading

    • Annealing Lehr Entry and Exit
      Annealing Lehr Entry and Exit

      The lehr must be sufficiently heated to prevent cracking or stress points in the glass. The LWIR-640 measures the cooling product at each end of this process to detect problems.

      Keep Reading

  • Documentation +

  • Videos +

    • Advances in Non-Contact Temperature Measurement for Glass Production
      On-demand Webinar

      We introduce how advances in accurate non-contact measurements across a range of applications and under a variety of different conditions ensures successful glass production and provides benefits in process and control. It considers key stages in the glass making process and specifically continuous temperature monitoring inside the glass melt furnace to ensure high product quality, detect structural damage and improve efficiency.
